Description

Equipment DetailsStandard
  • 2) 3500# Rubber torsion axles (7000# GVWR)
  • 1028H & 1030H – 2) 5200# Rubber torsion axles standard (9900# GVWR)
  • *Heavy axle upgrade available on models 1020H-1026H add’l cost
  • Electric brakes & breakaway kit
  • ST205/75R14 Radial tires or ST225/75R15 Radial tires
  • Aluminum wheels, 5-4.5 BHP or 6-5.5 BHP
  • Extruded aluminum floor
  • A-framed aluminum tongue with 2-5/16″ coupler
  • Bi-fold tailgate (2 individual gates) OR 2) 6′ Aluminum ramps
  • Front & side retaining rails (Trailers can be ordered without rails)
  • (Trailers can be ordered with side rub rail – 96″ bed width)
  • LED Lighting package, safety chains
  • 2) Fold-down rear stabilizer jacks
  • 4) Recessed tie rings, SS #5000
  • Dove tail, 48″ long with 8″ drop
  • Swivel tongue jack, 1500# capacity
  • Overall width = 101.5″
  • Overall length = 297″ / 322″ / 343″ / 370″ / 391″ / 420″
Optional
  • 1020H Upgrade to 2) 5200# axles-15″ Tires – Added frame strength (20′-26′ Lengths)
  • 20-0000787 Aluminum rock guard with top rail
  • 20-0000289 Aluminum rock guard
  • 60-0000650 Recessed Tie Down SS 2,000#
  • 60-0000646 Recessed Tie Down SS 5,000#
  • 50-0003658 Tie down loop
  • 20-0000781 60° Storage box (1020’s)
  • 20-0000007 Spare Tire Carrier Package 8″ 5 Bolt Vertical
  • 20-0001589 45° Storage box (1030’s)
  • 20-0000205 Spare tire mounting bracket, side rail mount, 5-bolt
  • 20-0001394 Upgrade 15″Aluminum wheel and tire TA
  • 20-0000008 8″ Vertical spare tire carrier, 6-bolt
  • 60-0001490 14″ Aluminum spare wheel & tire
  • 60-0001492 15″ Tire Silver Aluminum 5 Bolt
  • 60-0001494 15″ Aluminum spare wheel & tire – 6 bolt
  • 60-0000250 Adjustable coupler bracket
  • 60-0000252 2-5/16″ E-Z Latch adjustable coupler
  • 20-0001454 Hydraulic surge brakes

Specifications

ManufacturerAluma
Model1020 Deck Over Series
ConditionNew
Models1020TA-BT-DT-RR-RTD (Bi-fold Tailgate); 1022TA-BT-DT-RR-RTD (Bi-fold Tailgate); 1024TA-BT-DT-RR-RTD (Bi-fold Tailgate); 1026TA-BT-DT-RR-RTD (Bi-fold Tailgate); 1028H-TA-BT-DT-RR-RTD (Bi-fold Tailgate) *Heavy axle standard; 1030H-TA-BT-DT-RR-RTD (Bi-fold Tailgate) *Heavy axle standard; 1020TA-R-DT-RR-RTD (Ramps); 1022TA-R-DT-RR-RTD (Ramps); 1024TA-R-DT-RR-RTD (Ramps); 1026TA-R-DT-RR-RTD (Ramps); 1028H-TA-R-DT-RR-RTD (Ramps) *Heavy axle standard; 1030H-TA-R-DT-RR-RTD (Ramps) *Heavy axle standard
Weight1500#; 1575#; 1650#; 1725#; 2000#; 2225#; 1500#; 1575#; 1650#; 1725#; 2000#; 2225#
Bed Size100″ x 20′; 100″ x 22′; 100″ x 24′; 100″ x 26′; 100″ x 28′; 100″ x 30′; 100″ x 20′; 100 x 22′; 100 x 24′; 100 x 26′; 100 x 28′; 100 x 30′
Tires14″; 14″; 14″; 14″; 15″; 15″; 14″; 14″; 14″; 14″; 15″; 15″
