8200-14K TILT Series

or
Call 918-470-6790

Description

Equipment DetailsStandard
  • 2-7000# Rubber torsion axles – Easy lube hubs
  • Electric brakes, breakaway kit
  • ST235/80R16 Radial tires
  • Aluminum wheels, 8-6.5 BHP
  • Removable aluminum fenders
  • Extruded aluminum floor
  • 5 1/2″ Bump rail
  • A-Framed aluminum tongue, 56.5″ long with 2-5/16″ coupler
  • Stake pockets and rub rail
  • 30″ Beavertail
  • 6) Bolt-on heavy tie downs
  • 10K Spring-loaded drop leg jack
  • LED Lighting package, safety chains
  • Loading angle: 12° / 11.5° / 12.5°
  • Overall width = 101.5″
  • Overall length = 288″ / 308″ / 308″
Optional
  • Part # Description
  • 20-0001626 Airdam
  • 50-0004765 Extra stake pockets
  • 60-0000679 Bolt-on heavy duty tie-down
  • 60-0001496 16″ Aluminum spare wheel & tire
  • 40-0000060 Spare tire mounting bracket, side mount
  • 20-0001602 Package, Storage Box 14K Series

Specifications

ManufacturerAluma
Model8200-14K TILT Series
ConditionNew
Models8220-14K-TILT-4SF-TA-EL; 8222-14K-TILT-4SF-TA-EL; 8222-14K-TILT-6SF-TA-EL
Weight2650#; 2750#; 2750#
Bed Size79″ x 200″; 79″ x 224″; 79″ x 248″
Tires16″; 16″; 16″
