8200 Series Tandem
Description
Equipment DetailsStandard
- 2-3500# (8222H & 8224H = 2-5200#) Rubber torsion axles – Easy lube hubs
- Electric brakes, breakaway kit
- ST205/75R14 Radial tires or ST225/75R15 Radial tires
- Aluminum wheels, 5-4.5 BHP
- 40″ Spread axle and removable aluminum fenders (No spread axle on the 8212 and 8214 models)
- Extruded aluminum floor
- Front retaining rail
- A-Framed aluminum tongue, 48″ long with 2-5/16″ coupler
- 2) 6′ Aluminum ramps with storage underneath – 8212-5′ ramps
- Stake pockets – 8212-4 / 8214/16/18/20-6 / 8222H & 8224H-8
- 4) Recessed tie rings, SS 5000#
- 2) Fold-down rear stabilizer jacks (Only standard on 16′ and longer)
- Swivel tongue jack, 1500# capacity
- LED Lighting package, safety chains
- Overall width = 101.5″ / 101.5″/ 101.5″ / 101.5″ / 101.5″ / 100.5″ / 100.5″
- Overall length = 196″ / 224″ / 243″ / 272″ / 290″ / 320″ / 346″
- 8200TG Aluminum tailgate, no ramps
- 8200BT Bi-fold tailgate upgrade, no ramps
- 8200-SBT Split bi-fold tailgate
- 8200TR Top rail per foot
- 8200DT Dove tail, 8200 series
- 8200H Upgrade to 2) 5200# axles – 15″ tires
- 20-0000265 Front rock guard, 3500# axle
- 20-0000266 Front rock guard, 4800/5200# axle
- 20-0000267 8200 Series airdam assembly
- 50-0004765 Extra stake pockets
- 60-0000650 Recessed Tie Down SS 2,000#
- 60-0000646 Recessed Tie Down SS 5,000#
- 20-0000271 60° Storage box
- 20-0001394 15″ Alum wheel & tire upgrade (tandem)
- 20-0001981 Side mount spare tire bracket – 6 bolt
- 20-0001980 Side mount spare tire bracket – 5 bolt
- 60-0001490 14″ Aluminum spare wheel & tire
- 60-0001494 15″ Aluminum spare wheel & tire – 6 bolt
- 20-0000268 Winch mount assembly
- 20-0001454 Hydraulic surge brakes
Specifications
| Manufacturer | Aluma |
| Model | 8200 Series Tandem |
| Condition | New |
| Models | 8212TA-EL-R-RTD (Ramps); 8214TA-EL-R-RTD (Ramps); 8216TA-EL-R-RTD (Ramps); 8218TA-EL-R-RTD (Ramps); 8220TA-EL-R-RTD (Ramps); 8222HTA-EL-R-RTD (Ramps) *Heavy axle Standard; 8224HTA-EL-R-RTD (Ramps) *Heavy axle Standard |
| Weight | 1150#; 1250#; 1350#; 1450#; 1575#; 2000#; 2100# |
| Bed Size | 81″ x 144″; 81″ x 172″; 81″ x 192″; 81″ x 220″; 81″ x 240″; 81″ x 268″; 81″ x 295″ |
| Tires | 14″; 14″; 14″; 14″; 14″; 15″; 15″ |
